1. Introduction of equipment performance.
Operating principle of the whole machine.
SJ-1LB suppository filling production line has stable and efficient filling, sealing and other production processes, and production capacity of 1500 pills per hour.
Filling
And one-time molding suppository for embedded type filling, filling accuracy + / - 2%, filling material barrel has electric heating insulation system, the top is equipped with a uniform mixing machine in order to make drugs, drug by high precision in VAT filling pump into the filling head, a drug through the other end of the cycle to rest after filling material barrel filling again next time.
Sealing
After infusion, the suppository enters the sealing area: preheating mold (preheating), heating mold (heating), sealing die (batch number).
2. Function description
SJ-1LB suppository filling and sealing machine is suitable for the production of suppositories with special shapes such as bullet head, torpedo shape and duck's mouth shape.
PLC programmable control and man-machine interface operation, simple operation, convenient adjustment, accurate temperature control and smooth operation.
Temperature sensor and microcomputer control system are adopted to achieve high precision thermostatic control.
The liquid storage tank is made of 316L stainless steel, with the proper volume, with the function of heat preservation and heating, and accurate temperature control; The tank is equipped with a stirring device to ensure the homogeneity of the liquid in the barrel at any time. The liquid storage tank is connected with the filling mechanism through the pipe, and the medicine liquid is insulated and circulated to ensure the fluidity of the liquid and satisfy the need of filling.
Adopt the insertion type linear perfusion mechanism, locate the accurate, not drop the medicine, do not hang the wall; Single grain measurement 0.5-3.5ml, filling error plus or minus 2%.
Simple and reasonable design, easy operation and maintenance.
3. Main Parameters
output | 1000-1500 pcs/hour | single dosage | 0.5—3.5ml |
dosage allowed | ＜±2% | store the capacity of the liquid barrel | 20L |
consume the tolerance | 0.6m3/min | atmospheric pressure | ≥0.6Mpa |
water quantity | Temperature is adjustable from 5-35 degrees. | the voltage of the power | 3P 380V 50 HZ |
Adapt to the host | Synthetic fatty acid glycerin, polyethylene glycol, etc. | Total power | ≥4KW |
Each distance of suppository | 17.4mm | Weight | 550kg |
External dimension | L 2500mmxW 969mmxH 1819mm |
4. Configuration list
Programmable controller Communication module temperature module. | Siemens |
Touch screen | WEINVIEW 10 inch |
Low voltage electrical appliances | Schneider |
Temperature controller (multichannel temperature controller) | Yu electrical |
Solenoid valve gas source treatment. | Airtac(Taiwan) |
Photoelectric switch | Panasonic |
proximity switch. | Sodilong |
Warning device (alarm light) | Made in China |
