Max. Production Capacity (Blister/h)

Al-Al: 1200 (According to standard plate 80×57)

Al-plastic: 2400 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-Al: 70×90×14

Al-plastic: 70×110×26 (Standard 70×90×14)

Travel Range (mm)

20-100 (Can be manufactured as user's requirements)

Air Pressure (Mpa)

0.4-0.6

Standard Plate (mm)

80×57 (Can be manufactured as user's requirements)

Total Power

380V/220V  50Hz  1.8kw

Main Motor Power (kw)

0.75

PVC Rigid Sheet (mm)

0.15-0.5×100

PTP Aluminum Foil (mm)

0.02-0.035×100

Dialysis Paper (mm)

50-100g×100

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

1400×460×950（L×W×H）

Weight (kg)

450

1

Traction Pneumatic Cylinder

2

φ32×travel range 15

Wenzhou Yida

2

Main Motor

1

YS750W-4R

Taiwan Dongli

3

Heating Part

3

AL100×130

Jiangsu Taixing

4

Frequency Inverter

1

DVA-2S0007G

Drive

5

Feeding Motor

1

70-CK-25-K

Maili Co.

1

Thermocouple

2

LI-2M

Zhejiang Zhongpu

2

Air Breaker

1

DZ47-63/10A

Chint Group

3

Air Breaker

2

DZ47-63/6A

Chint Group

4

Air Breaker

1

DZ47-63/25A

Chint Group

5

Relay

5

HRS4H-S

Zhejiang Songle

6

SCM

1

Panel

China-foreign Joint Venture

7

Solid State Relay

2

SSR-25DA

Chint Group

8

Control transformer

1

JBK₃-63

Chint Group

9

Solenoid Valve

1

SG4V210-08

Wenzhou Yida

10

Emergency Stop

1

Y090-/11

Chint Group
